# 21218 - Drive End Frame for Ford 3G Series Large Case Alternators

21218 - Drive End Frame for Ford 3G Series Large Case Alternators

Used On: (2002-92) Ford, Mazda, Mercury

Unit Nos: Ford F3UZ-10346-A, F6UZ-10346-VA, F7RZ-10346-FA; Lester 7768, 7792

Dimensions:

• Mounting Ear Hole Size: 10mm
• Mounting Ear Thickness: 55mm
• Mounting Foot Hole Size: 10mm
• Mounting Foot to Bearing Center: 88mm
• Bearing Bore Diameter: 47mm
• Stator Bore Diameter: 142mm
• Frame OD: 148mm

Notes: Used w/ 6303 ball bearing
