# D411 - Voltage Regulator, 12 Volt, B-Circuit, P-L-I-S Terminals, 14.7 Vset, 2.5s LRC, Delco CS121, CS130, CS144 Series Alternators

D411
Voltage Regulator
12 Volt, B-Circuit, P-L-I-S Terminals, 14.7 Volt set point, 2.5 sec. LRC
For: Delco CS121, CS130, CS144 Series Alternators, For Heavy Duty Version see: D411XHD
Used On: (2000-87) Buick, Cadillac, Chevrolet, Dodge, Eagle, Geo,
GMC, Isuzu, Jeep, Oldsmobile, Pontiac, Saturn, Toyota
Unit Nos: Delco 1101101, 1101106, 1101107, 1101110, 1101111, 1101114,
1101119, 1101120, 1101121, 1101122, 1101123, 1101124, 1101125, 1101126,
1101127, 1101130, 1101131, 1101135, 1101136, 1101137, 1101138, 1101139,
1101140, 1101141, 1101142, 1101143, 1101144, 1101145, 1101148, 1101149,
1101150, 1101151, 1101153, 1101154, 1101160, 1101161, 1101162, 1101163,
1101165, 1101166, 1101167, 1101168, 1101170, 1101171, 1101172, 1101173,
1101174, 1101175, 1101176, 1101177, 1101179, 1101180, 1101181, 1101182,
1101183, 1101184, 1101185, 1101186, 1101187, 1101188, 1101189, 1101190,
1101191, 1101198, 1101208, 1101209, 1101210, 1101211, 1101212, 1101213,
1101214, 1101217, 1101218, 1101223, 1101227, 1101229, 1101230, 1101231,
1101232, 1101233, 1101234, 1101235, 1101237, 1101238, 1101239, 1101246,
1101247, 1101248, 1101249, 1101250, 1101253, 1101254, 1101255, 1101259,
1101263, 1101264, 1101266, 1101267, 1101271, 1101272, 1101273, 1101274,
1101275, 1101277, 1101278, 1101291, 1101292, 1101293, 1101310, 1101311,
1101313, 1101316, 1101317, 1101318, 1101319, 1101320, 1101321, 1101327,
1101344, 1101346, 1101349, 1101454, 1101461, 1101464, 1101465, 1101466,
1101467, 1101473, 1101475, 1101483, 1101486, 1101487, 1101491, 1101493,
1101495, 1101500, 1101521, 1101531, 1101563, 1101564, 1101565, 1101567,
1101573, 1101577, 1101580, 1101582, 1101583, 1101584, 1101593, 1101595,
1101596, 1101597, 1101599, 1101600, 1101601, 1101603, 1101604, 1101605,
1101606, 1101608, 1101612, 1101614, 1101615, 1101616, 1101617, 1101618,
1101619, 1101620, 1101621, 1101623, 1101626, 1101628, 1101629, 1101630,
1101632, 1101633, 1101634, 1101635, 1101636, 1101637, 1101638, 1101639,
1101642, 1101644, 1101645, 1101646, 1101647, 1101648, 1101649, 1101650,
1101802, 1101805, 1101807, 1101810, 1101812, 1101814, 1101815, 1101819,
1101822, 1101832, 1101843, 1101846, 1101849; 1102600, 1102601, 1102602,
1102603, 1102604, 1102607, 1102614, 1102615, 1102617, 1102625, 1102626,
1102629, 1102630, 1102631, 1102634, 1102637, 1102639, 1102641, 1102642,
1102643, 1102644; 1105661, 1105688, 1105694, 1105697, 1105698, 1105701,
1105710, 1105711, 1105712, 1105713, 1105714, 1105715, 1105716, 1105717,
1105718, 1105719, 1105720, 1105721, 1105722, 1105723, 1105725; 10430484;
10479800, 10479801, 10479802, 10479805, 10479806, 10479807, 10479808,
10479809, 10479814, 10479815, 10479816, 10479817, 10479836, 10479838,
10479839, 10479844, 10479847, 10479853, 10479854, 10479855, 10479874,
10479883, 10479884, 10479891, 10479893, 10479895, 10479896, 10479897,
10479898, 10479901, 10479902, 10479903, 10479904, 10479905, 10479906,
10479907, 10479909, 10479910, 10479911, 10479912, 10479913, 10479920,
10479921, 10479922, 10479937, 10479938, 10479954, 10479962, 10479963,
10479966, 10479969, 10479974, 10479989, 10479993, 10479997, 10479998;
10480010, 10480024, 10480025, 10480026, 10480027, 10480028, 10480035,
10480036, 10480037, 10480040, 10480067, 10480068, 10480069, 10480077,
10480082, 10480083, 10480084, 10480085, 10480086, 10480087, 10480090,
10480091, 10480092, 10480094, 10480097, 10480099, 10480104, 10480105,
10480111, 10480114, 10480115, 10480121, 10480122, 10480127, 10480130,
10480131, 10480133, 10480134, 10480136, 10480137, 10480138, 10480139,
10480157, 10480181, 10480200, 10480201, 10480202, 10480203, 10480206,
10480211, 10480255; 21021447, 21022772, 21022893; 21023516, 21023702,
21023724
Lester Nos: 7801, 7802, 7806, 7808, 7817, 7818, 7819, 7858, 7859, 7860,
7861, 7864, 7867, 7870, 7872, 7873, 7880, 7883, 7886, 7888, 7894, 7897;
7902, 7910, 7914, 7917, 7918, 7921, 7925, 7926, 7929, 7933, 7937, 7939,
7964, 7968, 7973, 7974, , 7984; 8103, 8106, 8107, 8112, 8114, 8119, 8130,
8137, 8153, 8154, 8163, 8165, 8167, 8169, 8171, 8172, 8173, 8179, 8198;
8203, 8204, 8214, 8215, 8217, 8218, 8219
Note: With temperature compensation.
For Heavy duty version See D411XHD.
(Ref. No: 35-127-6, 35-127)
