# D749XHD - Voltage Regulator 12 Volt, P-L-F-S Terminals, 14.8 Volt set point, 2.5 sec. LRC For: Delco CS130D Series Alternators

D749XHD
Voltage Regulator
12 Volt, B-Circuit, P-L-F-S Terminals, 14.8 Volt set point, 2.5 sec. LRC
Heavy Duty Version of D749 Voltage Regulator
For: Delco CS130D Series Alternators
Used On: 2005-96 Buick, Chevrolet, GMC, Oldsmobile, Pontiac, Marine,
Industrial and other applications with the CS130D Alternator
Unit Nos: Delco 10437987, 10437988, 10449257, 10480288, 10480292, 10480317, 10480318,
10480330, 10480331, 10480336, 10480346, 10480348, 10480352, 10480378, 15760058
Lester Nos: 8234, 8243, 8249, 8270, 8271, 8272, 8279, 8283
Features:
- Transpo Heavy Duty ASVR Design
- OE compliant functions & performance: current limiting, thermal shutdown,
load dump protection, shorted field & lamp circuit protection
- Welded construction - no solder joints for hi-temperature reliability & increased field life
