# IBR700 - Bridge Rectifier, Bosch Alternators, Rated to 300 Amp Output

IBR700 - Bridge Rectifier for Bosch Alternators - Rated up to 300 Amp Output

Dimensions: 126mm OD, M8 x 1.25 x 25mm Battery Terminal, M5 x 15mm D+ Terminal (Trio)

Notes: Delta stator applications.

Features: 100% New Transpo. 12-50A Avalanche Press Fit Diodes, 20-24 Volt rating

Used On: Audi (1997-2004) , Audi - Europe (1995-2002) , Land Rover (1999-2002) , Land Rover - Europe (1994-2002) , Mercedes - Europe (1996-2005) , Mercedes LCV - Europe (2000-2006) , Mercedes-Benz (1994-2003) , Volkswagen LCV - Europe (1998-2003)

Replaces:

AUDI VW

077-903-359

BOSCH

1-127-319-700, F-00M-053-201

Unit Nos:

AUDI VW

028-903-026J, 038-903-018D, 038-903-018DX, 038-903-018G, 059-903-015E, 074-903-025L, 074-903-025LX, 077-903-015F, 077-903-015K, 077-903-015L, 078-903-016

BOSCH

0-123-520-003, 0-123-520-004, 0-123-520-006, 0-123-520-007, 0-123-520-008, 0-123-520-010, 0-123-520-011, 0-123-520-012, 0-123-520-013, 0-123-520-014, 0-123-520-019, 0-123-520-020, 0-123-520-021, 0-123-520-022, 0-123-520-023, 0-123-520-026, 0-123-520-027, 0-123-520-031, B-120-510-758

LANDROVER

ERR5834

LETRIKA

IA 1044, IA 1044, IA 1108

MERCEDES

010-154-10-02, 010-154-29-02, 010-154-68-02, 010-154-71-02, 010-154-77-02, 010-154-83-02, 011-154-10-02, 011-154-70-02

LESTER

11108, 13773, 13773B, 13779, 13792, 13813, 22879, 23206, 23236
